SpanishTrolMaster's Carbon-X system provides critical monitoring of CO2 levels for up to 13 separate zones / rooms.
The system can have both high-level (up to 30,000ppm) and low-level (5,000ppm) alerts. The level limits are all user-adjustable in order to meet local regulations for supplemental CO2 usage indoors.
We offer a variety of modules for the Carbon-X system including a wide range of audio-visual alarm stations, CO2 sensors, and many different devices.
The Carbon-X system can fill all your CO2 monitoring needs for indoor grows, hydroponics, horticulture, and more.
(CDA-1) Carbon-X CO2 Alarm System
Regular price €550,20 Save €-550,20/
Overview
TrolMaster's Carbon-X system provides critical monitoring of CO2 levels for up to 13 separate zones / rooms. The system can have both high-level (up to 30,000ppm) alerts, as well as low-level (5,000ppm) alerts. Both high and low-level limits are user-adjustable to meet local regulations for supplemental CO2 use indoors.
The Carbon-X system can also control various devices such as ventilation fans, dampers, main CO2 valves as well as send a signal to the fire department by interfacing to the fire / alarm panel in the facility. Automatic shut-off of CO2 is accomplished by wiring the facility’s main CO2 solenoid in series with one of the system control modules. The settings for each of the devices connected to the system are user-selectable for easy customization.
Each room monitored by the Carbon-X will also require an audio-visual alarm to alert the person to the level of CO2 in the area, and whether or not it is safe to occupy the area.
The TrolMaster app can be used to remotely monitor the Carbon-X as well as to receive user-alert / notifications if high CO2 levels are detected.
The CDA-1 is the brain of the system.
Features
- Multiple Zones
- Customizable
- Plug and Play
- App connectivity
Specifications
|
Input Voltage : Max Sensors : Max controlled output : Working Temperature : Working Humidity : Package Dimensions: |
220-240VAC, 50/60Hz 13 pcs per Alarm channel 40 pcs 0-50°C ≤90% 27.5cm(L) x 16.4cm(W) x 6.2cm(H) |
Package Contents
- 1x CO2 Alarm System (CDA-1)
- 2x 16ft RJ12 Cable
- 1x 12V Power Adapter
- 1x Power Cable
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(MBS-K30) CO2 Sensor for Carbon-X
Regular price €385,35 Save €-385,35/
Overview
The ability to read up to 30,000 ppm CO2 is critical to the proper operation and safety of an emergency CO2 system like the Carbon-X. The MBS-K30 is Trolmaster’s newest CO2 sensor, which incorporates an NDIR 0-30,000 ppm sensor in a self-aspirated enclosure.
TrolMaster's MBS-K30 also features a built-in LCD display that will constantly display the current CO2 level (ppm). Each of the zones / rooms monitored by the Carbon-X can have 1 or 2 MBS-K30 CO2 sensors installed in order to satisfy local code requirements.
Please Note: The MBS-K30 requires the SPH-1 for supplemental power.
Features
- LCD display
- Plug and Play
Specifications
|
Working Temperature : Working Humidity : Package Dimensions : |
0-50°C ≤90% 27.5cm(L) x 16.4cm(W) x 6.2cm(H) |
Package Contents
- 1x MBS-K30
- 1x 16ft RJ12 Cable
- 1x T-Shape Splitter
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(DSE-2E) CO2 Emergency Stop Station
Regular price €109,20 Save €-109,20/
Overview
TrolMaster's DSE-1 CO2 Emergency Stop Station provides a simple method to shut off the CO2 supply when any fault or high CO2 level is detected. It is a 220V controlled outlet that supplies the power to CO2 solenoid valves in normal operation. The Carbon-X will then automatically shut off DSE-1 power if any fault or high CO2 level is detected within any of the installed CO2 sensors. If the DSE-1 loses communication with the Carbon-X, the power supply will also be disabled.
Features
- LED Power Indicator
- RJ12 Cable Socket
- Addressing
- Plug & Play
Specifications
|
Input Voltage: Output Current: Output Voltage: Working Temperature : Working Humidity : Package Dimensions: G.W. per pack: |
220~240 VAC, 50/60Hz 10A 220~240 VAC, 50/60Hz 0-50°C ≤ 90% 8.5cm(L) x 8cm(W) x 9cm(H) 0.34kgs |
Package Contents
- 1 x Emergency Stop Device Station
- 1 x 16ft RJ12 Cable
- 1 x 4ft RJ12 Cable
- 1 x RJ12 T-Splitter
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(ECS-1) RJ12 Extension Cable Set
Regular price €21,00 Save €-21,00/
Overview
TrolMaster modules and sensors all come complete with a RJ12 16ft cable, Y-splitter and RJ12 4 ft cable to connect to the Hydro-x. When connecting modules that are farther apart, you can use the Extension cable set ECS-1. The ECS-1 comes complete with another 16ft cable, Y-splitter and 4 ft cable.
Package Contents
- 1 x Male-to-Male 16ft RJ12 Cable
- 1 x Male-to-Male 4ft RJ12 Cable
- 1 x RJ12 T-Splitter
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(DSD-1) Dry Contact Station for Hydro-X system
Regular price €82,95 Save €-82,95/
Overview
The Trolmaster DSD-1 Dry-contact module provides a simple and flexible solution to the user’s who want to connect & control devices to the Hydro-X using a “dry-contact” or relay to activate the device. Some equipment requires either normally open or normally closed contact closure in order to activate the equipment. The DSD-1 is the product that you need to control those types of devices. It can be configured to work as the other Trolmaster power modules work, such as DST, DSH, DSC, DSH.
Comes with a cable set.
Features
- LCD Indicator
- Attaching Plug
- RJ12 Cable Socket
- Address Assignment
- Plug & Play
Specifications
|
Input Voltage : Output Current : Output Voltage : Working Temperature : Working Humidity : Packaging Dimensions : |
220~240 VAC, 50/60Hz 10A 220~240 VAC, 50/60Hz 0-50°FC ≤90% 8.5cm(L) x 8cm(W) x 9cm(H) |
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(SPH-1) RJ12 Splitter Hub
Regular price €34,65 Save €-34,65/
Overview
The SPH-1 Splitter Hub from TrolMaster makes the installation of our controllers as easy as plugging in a phone cable. The SPH-1 hub uses a single RJ12 cable input jack, and provides (8) individual RJ12 output jacks that can be connected to various TrolMaster sensors, adapters and device modules. Using the SPH-1 allows for a "clean" installation and eliminates the need for daisy-chain Y-splitters to be used to interconnect multiple modules or sensors.
The SPH-1 is also a powered hub, meaning that it will boost the signals passing through the SPH-1 allowing more modules, sensors and light adapters to be connected to the TrolMaster controllers. By using the SPH-1, an almost unlimited number of LED / HID lights can be controlled using a single TrolMaster controller. The SPH-1 comes complete with the SPH-1 hub, a 16 foot RJ12 cable and the 12vdc power supply.
The SPH-1 can be located in a central location with a single RJ12 cable connecting it to the main controller. From the SPH-1 hub, the individual RJ12 jacks can be connected to each of the sensors, device modules, or lighting adapters.
NOTE: If you are using the SPH-1 to interconnect your lighting systems together back to a single LMA adapter (except for LMA-T and ThinkGrow light system), DO NOT connect the 12 volt dc power supply to the SPH-1.
Package Contents
-
1x RJ12 Splitter Hub
-
1x 12V Power Adapter
-
1x 4 ft RJ12 Cable
Specifications
|
Input Voltage : Maximum Current : Working Temperature : Working Humidity : Packaging Dimensions : |
12VDC 1A 0-50°C ≤90% 16cm(L) x 8.5cm(W) x 9cm(H) |
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(AS-1) CO2 Alarm Station
Regular price €131,25 Save €-131,25/
Overview
TrolMaster's AS-1 CO2 Alarm Station is an audio/visual alarm to be mounted inside or outside the room to be monitored, and sound an alarm (both visible and audible) in the event of the CO2 level going above normal or safe levels. It can be linked to either low or high-level CO2 sensors, or it can be linked to both sensors for complete redundancy.
Features
- Plug and Play
- Dry Contact output
Specifications
|
Input Voltage : Output Current: Dry Contact Output: Working Temperature : Working Humidity : Package Dimensions : |
220~240 VAC, 50/60Hz 24V 0.2A 30VDC/250VAC,6A 0-50°C ≤ 90% 16cm(L) x 8cm(W) x 9cm(H) |
Package Contents
- 1 x DSD-1
- 1x Alarm
- 1 x 16ft RJ12 Cable
- 1 x 4ft RJ12 Cable
- 1 x RJ12 T-Splitter
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(AS-2) CO2 Alarm Station 2
Regular price €219,45 Save €-219,45/
Overview
TrolMaster's AS-2 CO2 Alarm Station combines an audio-visual alarm module with a color-coded LED display indicator and a LCD digital ppm level reading. It is designed to be mounted outside of the space to be monitored and will display the CO2 ppm level. The AS-2 can be linked to either the low or the high-level CO2 sensors, or it can be linked to both sensors for complete redundancy.
The green LED indicator shows the CO2 level is below 800ppm which means the room is safe to entry. The yellow LED indicator shows CO2 level equal to or above 800ppm which means supplemental CO2 is in use. The AS-2 will sound an audible alarm and blinking red LED indicator in the event of the CO2 level going above normal or safe levels.
Please Note: The AS-2 requires the SPH-1 for supplemental power.
Features
- Color-coded LED display indicator
- LED digital reading
- Plug & go
Specifications
|
Working Temperature : Working Humidity : Package Dimensions : |
0-50°F ≤90% 27.5cm(L) x 16.4cm(W) x 6.2cm(H) |
Package Contents
- 1x Alarm Station 2
- 1x 16ft RJ12 Cable
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(MC-1) Multifunction Crimper
Regular price €57,23 Save €-57,23/
Overview
TrolMaster's MC-1 Multifunction Crimper and Cable Tester is a premium-quality, all-in-one crimp tool, network cable tester, wire stripper and cutter. Network professionals can easily terminate and test network cables for wiring continuity, open configurations, shorts and mis-wires.
The MC-1 is an excellent addition to any network toolbox. This crimping tool and cable tester can quickly check terminations before IT staff install the customized cable. It also allows for quick identification and repair of connection problems in an existing installation.
Features
- All-in-one professional modular crimping tool with cutting, stripping and cable-testing functions
- Compatible with RJ45, RJ11, RJ12 and RJ22 plugs
- Cuts, strips, terminates and tests with one tool
- Tests patch cables and installed wiring
- Ratchet function
Specifications
|
Working Temperature : Working Humidity : Packaging Dimensions : Approx. G.W. per pack : |
0-50°C ≤90% 25.8cm(L) x 25.8cm(W) x 29.5cm(H) 4.44kgs |
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(ECS-500) 500ft RJ12 Cable Roll
Regular price €136,50 Save €-136,50/
Overview
Most sensors and control modules are connected by using standard RJ12 cable and splitters, making installation as simple as plug-and-play. TrolMaster provides the ECS-500 cable roll package for users to customize their own cables when the standard cables provided are not satisfied their needs.
Features
- Flat Type & White Color
Specifications
|
Working Temperature : Working Humidity : Packaging Dimensions : Approx. G.W. per pack : |
0-50°C ≤90% 25.8cm(L) x 25.8cm(W) x 29.5cm(H) 4.44kgs |
Package Contents
- 1x TrolMaster 500ft RJ12 Cable Roll
- 100x RJ12 Crystal Heads
- 100x Crystal Head Protectors
About us
The Mango Tech store was started by a veteran cultivator that wanted to provide the best, most advanced and most affordable environmental & irrigation controllers that have ever been created. Since its inception, the Mango Tech Store has partnered up with other likeminded companies, that share the same vision of bringing the best and highest quality products, into the agriculture industry. The Mango Tech store is tucked away near wine country in norther California, Rohnert Park to be exact. The staff working the store is a mixture of skills, some are knowledgeable growers with hands on experience with crops and the equipment we sell, and others are business oriented personnel with logistics experience, to expedite our clients orders in the fastest fashion. The Mango Tech store continually searches for new innovative products to add to the store, in hopes it will help our clients with efficiency in their gardens and also insuring bountiful healthy crops. We hope your business is blooming.
(TSB-1) TrolMaster Sensor Bracket
Regular price €16,80 Save €-16,80/
Overview
The TSB-1 TrolMaster Sensor Bracket is a wall mount specially designed for MBS-K30 / MBS-PRO. Users can mount the MBS sensor on the wall. Stay carefree with the curved-edge design which perfectly fits into the MBS sensors and is tightly locked.
*One set of TSB-1 contains 2 brackets for usage with one sensor
Features
- Easy installation
Specifications
|
Working Temperature : Working Humidity : Package Dimensions : |
0-50°C ≤ 90% 8.5cm(L) x 6.8cm(W) x 6.7cm(H) |
Package Contents
- 2x TrolMaster Sensor Bracket
